Tolomatic has the world's largest selection of rodless cylinders and pneumatic actuators

Order Tolomatic Band Cylinders Online



 TOLOMATIC manufacturers rodless cylinders— band cylinders, linear slides, cable cylinders and magnetically coupled cylinders/slides— and rod cylinder slides.

Tolomatic has a reputation for innovative linear motion products that is earned daily through the efforts of their Engineering, Operation, and Sales associates. Over 35% of Tolomatic's business comes from non-cataloged product solutions. In applications ranging from bottle capping to spot welding and packaging to material handling, put Tol-O-Matic products to work for you.







tolomatic rodless cylinders



A typical NFPA tie rod cylinder with a 2-inch body size and an 8-inch stroke, has an approximate overall length when the rod is extended of 21.75 inches.The equivalent 2-inch body size, 8-inch stroke rodless cylinder has an overall length of 14.3 inches. Since the rodless cylinder stroke is contained within the cylinder itself, there is a 34% smaller footprint than a rod style. As the stroke length increases, so does the space savings of a rodless cylinder.

SUPPORTED LOADS:



A rodless cylinder actuator guides and supports the load throughout the entire stroke length. Utilizing a variety of different bearing and load carrying design techniques, bending moments are better controlled resulting in long wear without seal or bearing stress.

BUILT-TO-ORDER:




All Tolomatic rodless cylinders are built to your specifications (in any incremental stroke length) in 5 days or less. You get what you want, when you want it.
